The driving system of AGV robot is mainly composed of driving power, motor and decelerating device. As a component that converts electrical energy into mechanical energy, the motor plays an important role in the AGV car. The determination of the performance parameters of the motor and the specifications and models of the deceleration device directly determines the power of the vehicle, that is, the moving speed and driving force of the vehicle directly determines the power characteristics of the vehicle.
There are many kinds of motors, and the main motors used in AGV include 4 kinds: DC brush motor, DC brushless motor, DC servo motor, and stepping motor. And no matter which kind of motor, it needs AGV motor plug to connect with other parts.
The good and bad of AGV motor connector can directly affect the use of AGV robot intelligent equipment, so if you want to choose a good AGV motor connector, you can refer to the following aspects:
Behaviour Of Electricity
The electrical performance of the connector mainly includes: limit current, contact resistance, insulation resistance and electrical strength. When connecting a high-power power supply, pay attention to the limit current of the connector.
Environmental Performance
The environmental performance of the connector mainly includes: temperature resistance, humidity resistance, salt spray resistance, vibration, impact and so on. Select according to the specific application environment. If the application environment is humid, the connector’s moisture resistance and salt spray resistance are required to avoid corrosion of the metal contacts of the connector. Therefore, it is particularly important to choose the AGV motor connector that corresponds to the environmental performance!
Mechanical Property
The mechanical properties of the connector include plugging force, mechanical anti-stay, etc. Mechanical anti-stay is very important to the connector, once inserted, it is likely to cause irreversible damage to the circuit!
Mode Of Connection
The connection mode refers to the connection mode between the contact pair of the connector and the wire or cable. Reasonable choice of termination mode and correct use of termination technology is also an important aspect of the use and selection of connectors. The most common are welding and crimping.
Compared with welding, high-quality AGV motor connectors should be crimped wiring, which can make connector products get better mechanical strength and electrical continuity and withstand harsher environmental conditions. It is also more suitable for intelligent equipment such as AGV robots than traditional welding methods.
Installation And Appearance
The shape of the connector is ever-changing, and the user mainly chooses from the straight, curved, outer diameter of the wire or cable and the fixed requirements of the shell, volume, weight, whether the metal hose needs to be connected, etc., and the connector used on the panel should also be selected from the aspects of beauty, shape, color, etc.
A wide variety of connectors, coupled with a wide range of application fields, in addition to the above AGV motor connector selection method, but also combined with the actual situation to choose the best connection scheme.
